What is a Pipe plate flange? tube sheet specifications, models, and parameters

Pipe plate flangeA hole slightly larger than the outer diameter of the pipe is drilled on the circular steel plate for fixing the pipe and the round steel fittings for sealing the medium. It is usually installed in a heat exchanger, and the pipe is penetrated and welded and fixed, thus playing the role of support and sealing. [Product Name] The machining accuracy, especially the distance between holes, the tolerance of pipe diameter, verticality and smoothness, has an important influence on the assembly and performance of chemical equipment.，is a popular Pipe plate flange。The following is to introduce the Pipe plate flange:

1、Brief introduction of Pipe plate flange

Pipe plate flangeIt is an accessory widely used in various industrial equipment.，Mainly used forEasy to maintain and repair.,Support and fixation,Adaptability and corrosion resistance,Sealing and leakage prevention andImprove heat transfer efficiency，the product looks beautiful.，High machining accuracy,corrosion-resistant,Good thermal conductivity,Excellent thermal conductivity,corrosion-resistant，widely used inLarge central air conditioner,steam turbine,pressure vessel,boiler,tubular exchanger and other industries。

Pipe plate flange

2、Introduction of advantages of Pipe plate flange

Pipe plate flanges have the following advantages.

1. Advanced technology

Modern Pipe plate flange production adopts many advanced technologies, such as centrifugal casting, numerical control drilling machine and so on, which improve the quality and performance of the Pipe plate flange.

2. Supporting and fixing action

As one of the skeletons of heat exchangers and other equipment, the Pipe plate flange is responsible for supporting and fixing the tubes to ensure that they will not be loosened or deformed due to fluid impact during work. This stability is very important for the long-term operation of the equipment.

3. High precision machining

With the application of numerical control technology, the machining accuracy of Pipe plate flanges has been significantly improved. High-precision machining ensures the close fit and efficient sealing between the Pipe plate flange and the tube.

4. corrosion resistance

According to the different use environment, the Pipe plate flange can be made of corrosion-resistant materials to cope with various harsh working conditions.

5. Improve heat transfer efficiency

In heat exchangers and other equipment, the contact surface between the Pipe plate flange and the tubes is the main channel for heat transfer. By optimizing the Pipe plate flange design and material selection, the efficiency of heat transfer can be improved, energy consumption can be reduced, and the whole equipment can be improved. performance

Pipe plate flange

3、Pipe plate flange application

Pipe plate flanges have the following purposes.

1. Condenser, evaporator, seawater desalination equipment

In these devices, Pipe plate flanges are also needed to support the fixed tubes to realize the processes of fluid condensation, evaporation and seawater desalination.

2. pressure vessel

In the pressure vessel, the Pipe plate flange is used to seal and fix the tubes to prevent medium leakage and ensure the safe operation of the vessel.

3. boiler

The Pipe plate flange also plays an important role in the boiler, which supports the fixed tubes and makes the boiler run stably and efficiently.

4. Condenser, evaporator, seawater desalination equipment

In these devices, Pipe plate flanges are also needed to support the fixed tubes to realize the processes of fluid condensation, evaporation and seawater desalination.

5. steam turbine

In the steam turbine, the Pipe plate flange may be used to support and fix some key components to ensure the normal operation of the steam turbine.

Pipe plate flange

4、Pipe plate flange customer scene picture

Pipe plate flange picture at a glance, showing elegance.。

Pipe plate flange

Note: All the pictures in this article were taken by Jianing forging manufacturer.。

5、Pipe plate flange video detail

You can buy Pipe plate flange according to your needs and show you product videos.。

Pipe plate flange

As you can see from the live video.，Shanxi jianing forging co., ltd It is a kind of fitting with specific holes drilled on circular steel plate, which are slightly larger than the outer diameter of the pipe to be penetrated.。

6、Jianing's after-sales service

On the premise of ensuring high quality and low price, Jianing forging can also provide customers with high-standard services, help customers choose appropriate specifications and models, and install and debug products on site for them free of charge. If customers have special requirements, our company can also train product operators in operation knowledge. Besides, if everyone's products fail at any time, our company will rush to the scene to solve them in a short time and deal with them in time.。

Jianing

Pipe plate flangeThe metal material makes the Pipe plate flange have good heat conduction performance, which is helpful for heat transfer in the heat exchanger.、The production adopts many advanced technologies, such as centrifugal casting and numerical control drilling machine, which improve the quality and performance of the Pipe plate flange.、According to the different use environment, the Pipe plate flange can be made of corrosion-resistant materials to cope with various harsh working conditions.、Depending on the use environment, the Pipe plate flange can be made of different materials, such as stainless steel, titanium alloy and other corrosion-resistant materials. This enables the Pipe plate flange to adapt to various harsh working conditions and prolongs the service life of the equipment.、Through accurate processing and assembly, it forms a close fit with the pipe, thus effectively sealing the fluid medium. This sealing function prevents fluid from leaking to the outside of the equipment, ensures the normal operation and safety of the equipment, and also avoids resource waste and environmental pollution.，Widely used inEasy to maintain and repair.,Support and fixation,Sealing and leakage prevention,Improve heat transfer efficiency,Adaptability and corrosion resistance and so on。
