Introduction to Irregular tube plate and tube sheet working principle

Irregular tube plateA hole slightly larger than the outer diameter of the pipe is drilled on the circular steel plate for fixing the pipe and the round steel fittings for sealing the medium. It is usually installed in a heat exchanger, and the pipe is penetrated and welded and fixed, thus playing the role of support and sealing. [Product Name] The machining accuracy, especially the distance between holes, the tolerance of pipe diameter, verticality and smoothness, has an important influence on the assembly and performance of chemical equipment.，usually used in steam turbine, boiler, tubular exchanger, pressure vessel, boiler and other fields，the product looks atmospheric.。

1、Brief introduction of Irregular tube plate

Irregular tube plateIt is an accessory widely used in various industrial equipment.。

Irregular tube plate

2、Functional advantages of Irregular tube plate

Irregular tube plates have the following advantages.

1. Advanced technology

Modern Irregular tube plate production adopts many advanced technologies, such as centrifugal casting, numerical control drilling machine and so on, which improve the quality and performance of the Irregular tube plate.

2. Sealing medium

Through accurate processing and assembly, the Irregular tube plate can effectively seal the fluid medium and prevent it from leaking to the external environment. This not only avoids resource waste and environmental pollution, but also ensures the safe operation of the equipment.

3. Supporting and fixing action

As one of the skeletons of heat exchangers and other equipment, the Irregular tube plate is responsible for supporting and fixing the tubes to ensure that they will not be loosened or deformed due to fluid impact during work. This stability is very important for the long-term operation of the equipment.

4. Adaptability and corrosion resistance

Irregular tube plates can be made of different materials and thicknesses according to different use environments and requirements to meet different pressure, temperature and corrosion conditions. This enables the Irregular tube plate to adapt to various harsh working conditions and prolongs the service life of the equipment.

5. Customizable production

Irregular tube plates can be customized according to actual working conditions and fluid characteristics to meet the needs of different customers. This flexibility makes Irregular tube plates widely used in various industrial equipment.

Irregular tube plate

3、Introduction of Irregular tube plate characteristics

Irregular tube plateit has the characteristics of High machining accuracy, corrosion resistance, Excellent thermal conductivity, Good thermal conductivity and Strong rigidity，is a popular Irregular tube plate。

Irregular tube plate

4、Irregular tube plate HD real shot

Jianing forging provides customers with on-site high-definition video, fully demonstrates the advantages of on-site productt operation, and helps customers to deeply understand the Irregular tube plate production process and production site, and gain favorable comments and recognition from customers.。

Irregular tube plate

As you can see from the live video.，Jianing forging the advantage is Through accurate processing and assembly, the fluid medium can be effectively sealed to prevent it from leaking to the external environment. This not only avoids resource waste and environmental pollution, but also ensures the safe operation of the equipment.、Structural design usually takes into account the convenience of maintenance. For example, some Irregular tube plates are connected by flanges, which is convenient for disassembly and maintenance.、Different materials and thicknesses can be selected according to different use environments and requirements to meet different pressure, temperature and corrosion conditions. This enables the Irregular tube plate to adapt to various harsh working conditions and prolongs the service life of the equipment.、The machining accuracy has been significantly improved. High-precision machining ensures the close fit and efficient sealing between the Irregular tube plate and the tube.、Depending on the use environment, the Irregular tube plate can be made of different materials, such as stainless steel, titanium alloy and other corrosion-resistant materials. This enables the Irregular tube plate to adapt to various harsh working conditions and prolongs the service life of the equipment.。

5、Irregular tube plate application

Irregular tube plates have the following purposes.

1. pressure vessel

In the pressure vessel, the Irregular tube plate is used to seal and fix the tubes to prevent medium leakage and ensure the safe operation of the vessel.

2. Condenser, evaporator, seawater desalination equipment

In these devices, Irregular tube plates are also needed to support the fixed tubes to realize the processes of fluid condensation, evaporation and seawater desalination.

3. boiler

The Irregular tube plate also plays an important role in the boiler, which supports the fixed tubes and makes the boiler run stably and efficiently.

4. steam turbine

In the steam turbine, the Irregular tube plate may be used to support and fix some key components to ensure the normal operation of the steam turbine.

5. Large central air conditioner

The Irregular tube plate plays a role in supporting and fixing the refrigerant pipe in large central air conditioning, which is helpful to the circulation of refrigerant and heat exchange.

Irregular tube plate

Irregular tube plateit is widely used intubular exchanger,Large central air conditioner,steam turbine,pressure vessel,boiler and other industries，is a common Irregular tube plate。
