Introduction to Elliptical hole tube plate flange, introduction to tube sheet function advantages and characteristics

Elliptical hole tube plate flangeIt is an accessory widely used in various industrial equipment.，the advantage is The machining accuracy has been significantly improved. High-precision machining ensures the close fit and efficient sealing between the Elliptical hole tube plate flange and the tube.、Depending on the use environment, the Elliptical hole tube plate flange can be made of different materials, such as stainless steel, titanium alloy and other corrosion-resistant materials. This enables the Elliptical hole tube plate flange to adapt to various harsh working conditions and prolongs the service life of the equipment.、As a key structural part in the equipment, it mainly plays the role of supporting and fixing the tubes (or pipes). It ensures that the pipe will not be loosened, displaced or deformed due to fluid impact, vibration or other external forces during the operation of the equipment.、It is often made of metal, which has strong rigidity and bearing capacity.、Convenient maintenance is usually considered in the structural design. For example, some Elliptical hole tube plate flanges are connected by flanges, which is convenient for disassembling and replacing pipes, thus reducing the maintenance cost and difficulty.，is a Elliptical hole tube plate flange newly developed by Jianing。

1、Brief introduction of Elliptical hole tube plate flange

Elliptical hole tube plate flangeIt is a kind of fitting with specific holes drilled on circular steel plate, which are slightly larger than the outer diameter of the pipe to be penetrated.，it can be used in tubular exchanger, pressure vessel, Large central air conditioner, tubular exchanger, steam turbine and other industries。

Elliptical hole tube plate flange

2、Introduction of Elliptical hole tube plate flange characteristics

Elliptical hole tube plate flangethe main features are High strength and rigidity, corrosion-resistant, Good thermal conductivity, Excellent thermal conductivity and High strength and rigidity，be loved by our customers.。

Elliptical hole tube plate flange

3、Elliptical hole tube plate flange video detail

Speak directly with facts on the spot。

Elliptical hole tube plate flange

As you can see from the live video.，Shanxi jianing forging co., ltd A hole slightly larger than the outer diameter of the pipe is drilled on the circular steel plate for fixing the pipe and the round steel fittings for sealing the medium. It is usually installed in a heat exchanger, and the pipe is penetrated and welded and fixed, thus playing the role of support and sealing. [Product Name] The machining accuracy, especially the distance between holes, the tolerance of pipe diameter, verticality and smoothness, has an important influence on the assembly and performance of chemical equipment.。

4、Elliptical hole tube plate flange application

Elliptical hole tube plate flanges have the following purposes.

1. tubular exchanger

The Elliptical hole tube plate flange plays the role of supporting and fixing the tubes in the tube-and-tube heat exchanger, ensuring that the tubes can be arranged stably and exchange heat effectively.

2. steam turbine

In the steam turbine, the Elliptical hole tube plate flange may be used to support and fix some key components to ensure the normal operation of the steam turbine.

3. pressure vessel

In the pressure vessel, the Elliptical hole tube plate flange is used to seal and fix the tubes to prevent medium leakage and ensure the safe operation of the vessel.

4. Condenser, evaporator, seawater desalination equipment

In these devices, Elliptical hole tube plate flanges are also needed to support the fixed tubes to realize the processes of fluid condensation, evaporation and seawater desalination.

5. Large central air conditioner

The Elliptical hole tube plate flange plays a role in supporting and fixing the refrigerant pipe in large central air conditioning, which is helpful to the circulation of refrigerant and heat exchange.

Elliptical hole tube plate flange

5、Introduction of advantages of Elliptical hole tube plate flange

The advantages of Elliptical hole tube plate flange are as follows:

1. Improve heat transfer efficiency

In heat exchangers and other equipment, the contact surface between the Elliptical hole tube plate flange and the tubes is the main channel for heat transfer. By optimizing the Elliptical hole tube plate flange design and material selection, the efficiency of heat transfer can be improved, energy consumption can be reduced, and the whole equipment can be improved. performance

2. Sealing medium

Through accurate processing and assembly, the Elliptical hole tube plate flange can effectively seal the fluid medium and prevent it from leaking to the external environment. This not only avoids resource waste and environmental pollution, but also ensures the safe operation of the equipment.

3. Easy to maintain and repair.

The structural design of Elliptical hole tube plate flanges usually takes into account the convenience of maintenance. For example, some Elliptical hole tube plate flanges are connected by flanges, which is convenient for disassembling and replacing pipes, thus reducing the maintenance cost and difficulty.

4. High heat conduction efficiency

The contact surface between the Elliptical hole tube plate flange and the tube is the main channel for heat transfer. Through the design and optimization of the Elliptical hole tube plate flange, the heat transfer efficiency of the heat exchanger can be improved and the energy consumption can be reduced. This is especially important for industrial processes that require efficient heat exchange.

5. corrosion resistance

According to the different use environment, the Elliptical hole tube plate flange can be made of corrosion-resistant materials to cope with various harsh working conditions.

Elliptical hole tube plate flange

6、company strength

The company has many years of Elliptical hole tube plate flange manufacturing experience, large scale and strong strength.。

Jianing forging

Elliptical hole tube plate flangethe product looks beautiful.，is a Elliptical hole tube plate flange，it has been widely used in boiler, pressure vessel, Large central air conditioner, tubular exchanger, boiler and other industries。
