Introduction to Integrated tube plate, advantages, characteristics and principles of tube sheet

Integrated tube plateIt is an accessory widely used in various industrial equipment.。The following is to introduce the Integrated tube plate:

1、Brief introduction of Integrated tube plate

Integrated tube plateIt is a kind of fitting with specific holes drilled on circular steel plate, which are slightly larger than the outer diameter of the pipe to be penetrated.，it can be used in tubular exchanger, pressure vessel, steam turbine, Large central air conditioner, steam turbine and other industries，it has the characteristics of High strength and rigidity, High machining accuracy, corrosion-resistant, Good thermal conductivity and Excellent thermal conductivity，was developed and designed by Jianing。

Integrated tube plate

2、Introduction of Integrated tube plate characteristics

Integrated tube platefeatures include Strong rigidity, High strength and rigidity, corrosion resistance, Good thermal conductivity and corrosion-resistant，A hole slightly larger than the outer diameter of the pipe is drilled on the circular steel plate for fixing the pipe and the round steel fittings for sealing the medium. It is usually installed in a heat exchanger, and the pipe is penetrated and welded and fixed, thus playing the role of support and sealing. [Product Name] The machining accuracy, especially the distance between holes, the tolerance of pipe diameter, verticality and smoothness, has an important influence on the assembly and performance of chemical equipment.。

Integrated tube plate

3、Integrated tube plate application

Integrated tube plates have the following purposes.

1. boiler

The Integrated tube plate also plays an important role in the boiler, which supports the fixed tubes and makes the boiler run stably and efficiently.

2. steam turbine

In the steam turbine, the Integrated tube plate may be used to support and fix some key components to ensure the normal operation of the steam turbine.

3. Condenser, evaporator, seawater desalination equipment

In these devices, Integrated tube plates are also needed to support the fixed tubes to realize the processes of fluid condensation, evaporation and seawater desalination.

4. pressure vessel

In the pressure vessel, the Integrated tube plate is used to seal and fix the tubes to prevent medium leakage and ensure the safe operation of the vessel.

5. Large central air conditioner

The Integrated tube plate plays a role in supporting and fixing the refrigerant pipe in large central air conditioning, which is helpful to the circulation of refrigerant and heat exchange.

Integrated tube plate

4、Integrated tube plate HD real shot

Jianing forging Integrated tube platethe product looks beautiful., the following is a panoramic shot of the Integrated tube plate for your reference.。

Integrated tube plate

Note: All the pictures in this article were taken by Jianing manufacturer.。

5、Introduction of advantages of Integrated tube plate

Integrated tube plates have the following advantages.

1. Convenient maintenance

The structural design of Integrated tube plates usually takes into account the convenience of maintenance. For example, some Integrated tube plates are connected by flanges, which is convenient for disassembly and maintenance.

2. Advanced technology

Modern Integrated tube plate production adopts many advanced technologies, such as centrifugal casting, numerical control drilling machine and so on, which improve the quality and performance of the Integrated tube plate.

3. Excellent thermal conductivity

The metal material makes the Integrated tube plate have good heat conduction performance, which is helpful for heat transfer in the heat exchanger.

4. Improve heat transfer efficiency

In heat exchangers and other equipment, the contact surface between the Integrated tube plate and the tubes is the main channel for heat transfer. By optimizing the Integrated tube plate design and material selection, the efficiency of heat transfer can be improved, energy consumption can be reduced, and the whole equipment can be improved. performance

5. High precision machining

With the application of numerical control technology, the machining accuracy of Integrated tube plates has been significantly improved. High-precision machining ensures the close fit and efficient sealing between the Integrated tube plate and the tube.

Integrated tube plate

Integrated tube platethe main features are corrosion resistance, High strength and rigidity, Strong rigidity, Excellent thermal conductivity and High machining accuracy，is a common Integrated tube plate，A hole slightly larger than the outer diameter of the pipe is drilled on the circular steel plate for fixing the pipe and the round steel fittings for sealing the medium. It is usually installed in a heat exchanger, and the pipe is penetrated and welded and fixed, thus playing the role of support and sealing. [Product Name] The machining accuracy, especially the distance between holes, the tolerance of pipe diameter, verticality and smoothness, has an important influence on the assembly and performance of chemical equipment.。
