Introduction to Integral pipe plate flange and tube sheet advantages and features

Integral pipe plate flangeIt is a kind of fitting with specific holes drilled on circular steel plate, which are slightly larger than the outer diameter of the pipe to be penetrated.，is a popular Integral pipe plate flange，be of high quality，low in price。

1、Brief introduction of Integral pipe plate flange

Integral pipe plate flangeIt is an accessory widely used in various industrial equipment.，It has a wide range of uses, and is often used inSupport and fixation,Improve heat transfer efficiency,Easy to maintain and repair.,Adaptability and corrosion resistance,Sealing and leakage prevention and so on。

Integral pipe plate flange

2、Integral pipe plate flange video

You can buy Integral pipe plate flange according to your needs and show you product videos.。

Integral pipe plate flange

As you can see from the live video.，Jianing forging the product looks atmospheric.。

3、Integral pipe plate flange advantage

The advantages of Integral pipe plate flange are as follows:

1. Adaptability and corrosion resistance

Integral pipe plate flanges can be made of different materials and thicknesses according to different use environments and requirements to meet different pressure, temperature and corrosion conditions. This enables the Integral pipe plate flange to adapt to various harsh working conditions and prolongs the service life of the equipment.

2. Sealing and leakage prevention

Through precise machining and assembly, the Integral pipe plate flange forms a close fit with the pipe, thus effectively sealing the fluid medium. This sealing function prevents fluid from leaking to the outside of the equipment, ensures the normal operation and safety of the equipment, and also avoids resource waste and environmental pollution.

3. High heat conduction efficiency

The contact surface between the Integral pipe plate flange and the tube is the main channel for heat transfer. Through the design and optimization of the Integral pipe plate flange, the heat transfer efficiency of the heat exchanger can be improved and the energy consumption can be reduced. This is especially important for industrial processes that require efficient heat exchange.

4. Convenient maintenance

The structural design of Integral pipe plate flanges usually takes into account the convenience of maintenance. For example, some Integral pipe plate flanges are connected by flanges, which is convenient for disassembly and maintenance.

5. Easy to maintain and repair.

The structural design of Integral pipe plate flanges usually takes into account the convenience of maintenance. For example, some Integral pipe plate flanges are connected by flanges, which is convenient for disassembling and replacing pipes, thus reducing the maintenance cost and difficulty.

Integral pipe plate flange

4、Integral pipe plate flange characteristics

Integral pipe plate flangeExcellent thermal conductivity,High machining accuracy,corrosion resistance,corrosion-resistant,Good thermal conductivity，be loved by our customers.。

Integral pipe plate flange

5、Integral pipe plate flange real beat

Jianing forging Integral pipe plate flange, product manufacturer, product features, is the ideal choice for new and old customers.。

Integral pipe plate flange

Note: All the pictures in this article were taken by Jianing manufacturer.。

6、Integral pipe plate flange real shot picture

HD picture of Jianing forging Integral pipe plate flange,Strong rigidity。

Integral pipe plate flange

Note: All the pictures in this article were taken by Jianing manufacturer.。

Integral pipe plate flangeA hole slightly larger than the outer diameter of the pipe is drilled on the circular steel plate for fixing the pipe and the round steel fittings for sealing the medium. It is usually installed in a heat exchanger, and the pipe is penetrated and welded and fixed, thus playing the role of support and sealing. [Product Name] The machining accuracy, especially the distance between holes, the tolerance of pipe diameter, verticality and smoothness, has an important influence on the assembly and performance of chemical equipment.，is a kind of high quality and low price Integral pipe plate flange。
